To purchase parts for the American 12 (Belt Guard Assembly):

  1. Reference the part needed from the parts diagram and refer to the parts list below.
  2. Copy the Part Number and paste it into the search window above to see availability and pricing.
  3. Confirm your parts selection and "Add To Cart".

American 12 belt guard

ItemPart Number QtyDescription
121902C2Clamp - Belt Guard - Black
223801A1Guard - Belt Pntd
326000C1Nut - Black
451113A2Ball 1/2 C. R. Steel
668001A1Stud-Guard Belt
786202A2Scr 5/8-11x5/8 St St
887006A31/2 Uss Std Flat Washer Pltd
99628924Screw 1/4-20 Unc X 3/4 Pan Head
109806574Washer, Lock 1/4
