| Item | Part Number | QTY | Description | | Item | Part Number | QTY | Description | | Item | Part Number | QTY | Description |
| 1 | 42201A | 1 | CORDSET- HARD SERVICE 100FT | | 18 | 81102A | 2 | NUT STOP ELASTIC 1/4-20 HEX | | 36 | 45608A | 1 | PLUGELECTRICAL NEMA L6-20P |
| 42302A | 1 | CORD,POWER,240 V, CLASSIC 8 | | 19 | 64405A | 1 | HANDLE-STEERING | | 37 | 60401A | 1 | ARM-CABLE |
| 2 | 962065 | 3 | SCREW 8-32 X 1/4 PN ST PH | | 20 | 21904C | 1 | CLAMP STEERING HANDLE - BLACK | | 38 | 62800A | 1 | PIPE ASSY |
| 3 | 41706A | 1 | CONNECTOR ELECT. NEMA L6-20R | | 21 | 60724A | 1 | BELT-OPERATING | | 39 | 60721A | 1 | BAG ASSEM. 8&12 SANDERS |
| 4 | 43501A | 1 | INLETFLANGED NEMA L6-20P | | 22 | 85818A | 1 | SCREW5/16-18 X 2 1/2 HX HD | | 40 | 41707A | 1 | CONNECTOR ELECT. NEMA L6-30R |
| 5 | 85313C | 4 | SCREW 6-32 X 3/8 PAN HD | | 23 | 60016A | 1 | PIPE, HANDLE (DELCO BLACK) | | 41 | 41917A | 1 | CORD-INTERCONNECTING |
| 6 | 962794 | 5 | SCREW 10-24X1 PN ST PH | | 24 | 86200A | 2 | SCR 3/8 -16X 5/8 ST ST DOGPT | | 42 | 23200C | 1 | HANDLE MOUNT - BLACK |
| 7 | 980650 | 7 | WASH .19 x .34 x .04 LOCK | | 25 | 962288 | 5 | SCREW 3/8-16 X 1.0 HX ST CAP | | 43 | 980022 | 2 | WASHER WAVE |
| 8 | 980607 | 4 | WASHER 6 EXT TOOTH PLTD | | 26 | 82104A | 1 | NUT,LOCK,3/4 CONDUIT | | 44 | 53538A | 1 | ROD END 3/8-24 L.H. FEMALE |
| 9 | 22127C | 1 | COVER SWITCH BOX - BLACK | | 27 | 85816A | 1 | SCREW 5/16-18 X 1 3/4 HX HD | | 45 | 925036 | 1 | PIN-3/32X3/4 COTTER |
| 10 | 41411A | 1 | CIRCUIT BREAKER 30 AMP | | 28 | 20704C | 1 | SWITCH BOX - BLACK | | 46 | 66150A | 1 | PIPE WLDMT DUST CLASSIC 8 |
| 11 | 48901A | 1 | WIRE ASSEMBLY | | 29 | 980699 | 3 | WASHER SH 1210-00 | | 47 | 920342 | 1 | NUT LK 3/8-16 REG |
| 12 | 962015 | 5 | SCREW 10-24 X 3/8 PN ST PH | | 30 | 69441A | 1 | BRACKET, CONTROL LEVER | | 48 | 980651 | 1 | WASHER 5/16 SAE FLAT |
| 13 | 920110 | 4 | NUT LK 5/16-18 REGPLTD | | 31 | 51074A | 2 | CLAMP CABLE | | 49 | 38109A | 1 | SEAL DUST PIPE FLOOR SANDERS |
| 14 | 80022A | 1 | BOLT SHOULDER 1/2 X 5/8 | | 32 | 80035A | 2 | BOLT SHOULDER 3/8 X 1 1/4 | | 50 | 49023A | 2 | WIRE ASSEMBLY |
| 15 | 898203 | 1 | SPACER ROD END HK-8 | | 33 | 53537A | 1 | ROD END 3/8-24 R.H. FEMALE | | 51 | 48901A | 1 | WIRE ASSEMBLY |
| 16 | 25603A | 1 | LEVER CONTROL HK-8 | | 34 | 920204 | 1 | NUT-3/8-24 HEX JAM | | 52 | 85517A | 2 | SCREW 10-24X1/2 PN SB TP-T PH |
| 17 | 962481 | 2 | SCR 1/4-20 X 1-1/4 HEX ST CAP | | 35 | 67150A | 1 | ROD CONTROL HK-8 | | | 77039B | 1 | LABEL MADE IN THE USA |
