| Item | Part Number | QTY | Description | | Item | Part Number | QTY | Description | | Item | Part Number | QTY | Description |
| 1 | 41945A | 1 | CORDMOTORCLASSIC 8 | | 28 | 65304A | 1 | KNOBMOTOR MTG8 BELT SANDER | | 55 | 171101 | 1 | NUT LK-FLANGE 3/8-16 PLTD |
| 2 | 45604A | 1 | PLUGELECT. NEMA L6-30P | | 29 | 65959A | 1 | MOUNT, MOTOR, FRONT (HK-8) | | 56 | 60414A | 1 | ARMIDLERPNTD8 BELT SANDER |
| 3 | 962330 | 4 | SCREW 6-32 X 3/8 PAN HD | | 30 | 51024A | 1 | BELT DRUM AMERICAN 8 | | 57 | 67875A | 1 | SPACER CLASSIC 8 |
| 4 | 73715A | 1 | PLATE ELEC/FIRE WARNING HK-8 | | 31 | 65960A | 1 | MOUNT, MOTOR, REAR (HK-8) | | 58 | 57801A | 1 | RING-SNAP 26X1.2 |
| 6 | 170674 | 2 | CONNECTORWIRE NUT-RED | | 32 | 81202A | 1 | NUT 7/16-14 HX ST LH | | 59 | 902619 | 1 | BEARING 580/590 TB16 |
| 7 | 697502 | 1 | STRAIN RELIEF-BUSHING SR 8L-1 | | 33 | 87002A | 1 | WASHERFLAT | | 60 | 66170A | 1 | PULLEY IDLER -3L CLASSIC 8 |
| 8 | 980614 | 2 | WASHER LK 1/4 EXT TOOTHPLTD | | 34 | 34264A | 1 | GASKET 32 DLX | | 61 | 962216 | 1 | SCREW 3/8-16 X 1-1/4 HX HD |
| 9 | 962823 | 2 | SCR 1/4-20 X 1/2 PN ST PH | | 35 | 23301A | 1 | FAN | | 62 | 81108A | 1 | NUTHEX ELASTIC LOCK3/8-24 |
| 10 | 47378A | 1 | SWITCH MOTOR STARTING CLASSI | | 36 | 61602A | 1 | COLLAR | | 63 | 920110 | 1 | NUT LK 5/16-18 REGPLTD |
| 11 | 41305A | 2 | CAPACITOR ELECTR 161-193MFD | | 37 | 902567 | 1 | BEARING BALLDOUBLE SEALED | | 64 | 68010A | 1 | STUDIDLER ARM8 BELT SANDER |
| 12 | 41304A | 1 | CAPACITOR OIL FILLED 40MFD | | 38 | 22126C | 1 | FAN COVER - BLACK | | 65 | 86111A | 1 | SCREW1/4-20 X 1/2SOCKET HEAD |
| 13 | 22904A | 1 | ENCLOSUREMTR STRTPNTD APOLL | | 39 | 65302A | 1 | KEY-WOODRUFFSPECIAL | | 66 | 980657 | 1 | WASHER LOCK 1/4 STD |
| 14 | 962244 | 1 | BOLT 3/8-16 X HHCS | | 40 | 67445A | 1 | SHAFTFAN8 BELT SANDER | | 67 | 61600A | 1 | CLIP-DUST |
| 15 | 87034A | 1 | RETAINERMTR PULLEY CLASSIC 8 | | 41 | 85813A | 3 | SCREW 5/16-18 X 1 HX HD | | 68 | 67614A | 1 | SHOE DUST HK-8 |
| 16 | 51032A | 1 | BELT FAN APOLLO 8 | | 42 | 51111A | 1 | BEARINGBALL | | 69 | 66971A | 1 | RETAINER,BUMPER,FRONT,PLTD |
| 17 | 66189A | 1 | PULLEY MOTOR HK-8 | | 43 | 877304 | 1 | RINGRETAININGINTERNAL8 BEL | | 70 | 31232A | 1 | BUMPER FRONT HK-8 |
| 18 | 57712A | 1 | RINGRETAININGMOTOR SHAFT8 | | 44 | 66169A | 1 | PULLEY FAN AMERICAN 8 | | 71 | 25906A | 1 | MAINFRAMEPNTD APOLLO 8 |
| 19 | 915098 | 1 | Key, 1/4 Sq. x 1 1/4 | | 45 | 80017A | 1 | BOLT SHOULDER 3/8 X 2 3/4 | | 72 | 87700A | 4 | SCREW1/4-20 X 1/2 BUTTON HEAD |
| 20 | 44639A | 1 | MOTOR4 HP 230/60CLASSIC 8 | | 46 | 23808A | 1 | GUARD,BELT,PNTD (APOLLO 8) | | 73 | 64489A | 1 | HANDLE WLDMTLIFTFRONTPNTD |
| 44664A | 1 | MOTOR2.2KW 240V 50HZ LOW INRU | | 47 | 85700A | 1 | SCR 1/4 -20X1 HX ST CAP | | 74 | 930093 | 2 | POP RIVET 1/8X1/4-5/16 |
| 21 | 920342 | 1 | NUT LK 3/8-16 REG | | 48 | 31221A | 1 | BUMPERSIDE8 BELT SANDER | | 75 | 74045A | 1 | PLATEDANGERMOVING PARTSCLAS |
| 22 | 32357A | 4 | COVERHANDLECLASSIC 8 | | 49 | 66932A | 1 | RETAINERBUMPERSIDEPLTD8 B | | 76 | 77234A | 1 | LABELWARNINGHEAVY OBJECT |
| 23 | 64460A | 1 | HANDLE WLDMTMOTOR LIFTPNTD8 | | 50 | 85517A | 8 | SCREW 10-24X1/2 PN SB TP-T PH | | | 52768A | 1 | Front Cover |
| 24 | 962870 | 1 | SCR 3/8 -16X1 BT ST ALLEN | | 51 | 81102A | 2 | NUT STOP ELASTIC 1/4-20 HEX | | | 53998A | 1 | FAN CLASSIC-8 |
| 25 | 52769A | 1 | COVER FAN CLASSIC-8 | | 52 | 68393A | 1 | TUBELATCHPNTD8 BELT SANDER | | | 52769A | 1 | COVER FAN CLASSIC-8 |
| 26 | 85703A | 4 | SCR 3/8 -16X1&1/2 HX ST CAP | | 53 | 60623A | 1 | BRACKETLATCHPNTD8 BELT SAN | | | 51188A | 1 | BEARING RADIAL BALL CLASSIC 8 |
| 27 | 68394A | 1 | T-SCREWBELT TENSION8 BELT S | | 54 | 85702A | 1 | SCR 1/4 -20X1&3/4 HX ST CAP | | | 902547 | 1 | BEARING 6205 |
| | | | | | | | | | | 40316A | 1 | Armature Assembly |
